Horizontal Vacuum Furnaces
Advanced horizontal vacuum furnace systems designed for precision heat treatment, brazing, and sintering applications.
Products
Engineered for Peak Performance
VAH Series furnaces incorporate advanced design features for optimal efficiency, uniformity, and reliability, ensuring consistent results for your most demanding thermal processing needs.
The VAC AERO VAH Series represents the pinnacle of horizontal vacuum furnace technology, designed for a wide range of thermal processing applications including hardening, tempering, annealing, brazing, and sintering. Each system is meticulously engineered to provide precise temperature control, uniform heating, and superior metallurgical results.
Superior Temperature Control
Our advanced multi-zone heating systems deliver exceptional temperature uniformity of ±5°F (±3°C) throughout the work zone, ensuring consistent metallurgical results across your entire load.
Precision Vacuum Performance
Achieve ultimate vacuum levels in the 10⁻⁶ torr range with our high-performance pumping systems, providing the clean processing environment critical for aerospace and medical applications.
Superior Temperature Uniformity
Achieves ±5°F (±3°C) or better, meeting stringent aerospace and industrial standards like AMS 2750.
High Vacuum Performance
Capable of reaching vacuum levels in the 10⁻⁶ torr range for ultra-clean processing environments.
Rapid Gas Quenching
Optional high-pressure gas quench systems (up to 10 bar) for controlled cooling and optimized material properties.
Modular Hot Zone Design
Graphite or all-metal hot zones designed for easy maintenance, longevity, and specific process requirements.
Advanced Process Control
PLC-based systems with intuitive HMI, recipe management, data logging, and SCADA integration capabilities.
Robust Construction
Heavy-duty furnace bodies and components built for durability and reliable operation in demanding industrial settings.
VAH Series Horizontal Vacuum Furnace - Main View
VAH Series Hot Zone Components
Detailed side view of a VAH Series Horizontal Furnace
Interior view of a VAH Series Horizontal Furnace Hot Zone
Custom engineered VAH Series system in a facility
VAH Series: Precision Engineered
Horizontal Vacuum Furnace Systems
These furnaces deliver exceptional temperature uniformity, precise atmospheric control, and robust performance for critical industries such as aerospace, automotive, medical, and tool & die. Each VAH furnace is built with high-quality materials and components, ensuring long-term reliability and operational efficiency.
Technical Documents
Technical Specifications
Explore the comprehensive engineering details and performance capabilities.
VAH Series furnaces are available in a range of standard sizes to accommodate various load capacities and processing volumes. Custom sizes can be engineered upon request.
| Model | Work Zone (W×H×D) | Max Load | Max Temp |
|---|---|---|---|
| VAH-2436 | 24" × 24" × 36" | 1,000 lbs | 2400°F (1315°C) |
| VAH-3648 | 36" × 36" × 48" | 2,500 lbs | 2400°F (1315°C) |
| VAH-4860 | 48" × 48" × 60" | 4,000 lbs | 2400°F (1315°C) |
| VAH-5472 | 54" × 54" × 72" | 5,000 lbs | 2400°F (1315°C) |
Ready to Discuss Your Requirements?
Our engineering team is ready to help you select or design the optimal VAH Series horizontal vacuum furnace for your specific application.
